Technical Specification
Widths, constructions, patterns and the information we need from you before quoting quilted fibreglass.
How To Read This Specification
Quilted fibreglass is built to order rather than sold from a fixed catalogue, so the specification below describes the envelope we work within rather than a single product.
Width and roll winding
Width: quilted up to 2400mm; most orders run between 1500mm and 2400mm. Rolls are wound to a length that suits your handling — tell us the maximum roll weight your team can lift and we will wind to it.
Construction options
Construction: one fibreglass mat between two facing fabrics as standard. Multi-layer builds, single-faced constructions and composites incorporating a foil or a scrim are all possible; each needs a sample run before production.
- Maximum width
- 2400mm
- Standard patterns
- Vertical 1–2", box 2" and 4"
- Construction
- Mat between two facings; multi-layer to order
- Sample panels
- Supplied free on a live enquiry
More in quilted insulation
- Quilted FibreglassHigh-performance quilted fibreglass insulation
- Fire & Welding BlanketsHeat and spark-resistant protective blankets
- Industrial Jackets & Plant InsulationInsulation jackets for plant and machinery
- Fibreglass vs polyester waddingCompare materials to find the right fit
- Bulk supply & lead timesVolume orders with reliable turnaround
- Request a sampleFree sample panels on a live enquiry
Performance claims and where testing sits
.png&w=3840&q=75)
Performance claims: thermal conductivity, continuous service temperature and reaction-to-fire classification are properties of the specific mat and facings in your build and of the finished article, rather than of roll goods. We publish the constructions we can make and pass through the material data for the components; testing and classification of the finished product sits with you or your test house — we will quilt sample panels for submission at no charge on a live enquiry.
What to send with an enquiry
What to send with an enquiry: operating temperature, environment (indoor, outdoor, washdown, oil contact), required finished width, annual or per-order quantity, any facing fabric or mat you need us to use, and the standard the end product is being tested against.
.png&w=3840&q=75)
Tell us what you need quilting
Send us your fabric and filling, tell us the pattern, and we will quote you on the work.
